Question
Explain geometry of $H_2O$ molecule according to $\text{VSEPR}$ theory.
✓
Answer
In $H_2O$ molecule, the central atom oxygen has six electrons in its valence shell. On bond formation with two hydrogen atoms, there are $8$ electrons in the valence shell of oxygen. Out of these, two pairs are bond pairs and two are lone pairs.
Due to lone pair – lone pair repulsion, the lone pairs are pushed towards the bond pairs and bond pair – lone pair repulsions become stronger thereby reducing the $H-O-H$ bond angle from $109^\circ 28′ \ to \ 104^\circ 35′$ and the geometry of the molecule becomes angular $($bent$).$
Diagram:
Due to lone pair – lone pair repulsion, the lone pairs are pushed towards the bond pairs and bond pair – lone pair repulsions become stronger thereby reducing the $H-O-H$ bond angle from $109^\circ 28′ \ to \ 104^\circ 35′$ and the geometry of the molecule becomes angular $($bent$).$
Diagram:
Need a full question paper?
Generate a complete, print-ready paper with questions like this in minutes — across 16+ boards, with answer keys.
Explore more
Similar questions
Describe the various methods used for preparation of calcium carbonate.
Calculate the mass of carbon dioxide and water formed on complete combustion of 24 g of methane gas. (Atomic masses, C = 12 u, H = 1 u, O = 16 u)
Based on the above diagram, answer the following questions:
$i.$ Name the chromatographic technique involved.
$ii.$ From the developed chromatogram, state which has the highest and which has the lowest $R_f$ value?
$iii.$ Based on the $\text{TLC,}$ which component would elute out at the end of a column chromatography?
$iv.$ Mention two applications of $\text{TLC}$ method.
Write the Lewis structure of $CO$ molecule.
→Display electron distribution around the oxygen atom in water molecule and state shape of the molecule, also write H-O-H bond angle.
32 g of oxygen reacts with some carbon to make 56 grams of carbon monoxide. Find out how much mass must have been used.
Explain the trend in electronegativity
i. across a period
ii. down a group
i. across a period
ii. down a group
Explain the rules for naming mono or polyfunctional compounds.
