The bond order of O_2^ + is the same as in - Vidyadip

MCQ

The bond order of $O_2^ + $ is the same as in

✓
$N_2^ + $
B
$C{N^ - }$
C
$CO$
D
$N{O^ + }$

✓

Answer

Correct option: A.

$N_2^ + $

(a) $O_2^ + (15{e^ - }) = K{K^*}{(\sigma 2s)^2}{({\sigma ^*}2s)^2}{(\sigma 2{p_x})^2}$

${(\pi 2{p_y})^2}{(\pi 2{p_z})^2}{({\pi ^*}2{p_y})^1}{({\pi ^*}2{p_z})^0}$

Hence, bond order $ = \frac{1}{2}(10 - 5) = 2.5$$N_2^ + (13{e^ - }) = K{K^*}{(\sigma 2s)^2}{({\sigma ^*}2s)^2}{(\sigma 2{p_x})^2}$

${(\pi \,2{p_y})^2}{(\pi \,2{p_z})^1}$

Hence, bond order $ = \frac{1}{2}(9 - 4) = 2.5$.
