The equivalent resistance between $A$ and $B$ is $......$
JEE MAIN 2023, Medium
Download our app for free and get started
a
$\frac{1}{ R _{ eq }}=\frac{1}{2}+\frac{1}{12}+\frac{1}{4}+\frac{1}{6}+\frac{1}{2}$
$\frac{1}{ R _{ eq }}=\frac{1}{2}+\frac{1}{12}+\frac{1}{4}+\frac{1}{6}+\frac{1}{2}$
$=\frac{6+1+3+2+6}{12}=\frac{18}{12}=\frac{3}{2}$
$\Rightarrow \quad R_{ eq }=\frac{2}{3}\,\Omega$
