- Each carbon atom is linked to four other carbon atoms.
- A diamond crystal has a tetrahedral arrangement of carbon atoms.
Graphite:
- Each carbon atom is joined to only three other carbon atoms.
- A graphite crystal has flat hexagonal rings structure.
50 questions · timed · auto-graded
Graphite:
C20H2×20 + 2 = C20 H42
C20H20×2 = C20H40
C20H2×20-2 = C20H38



The reaction in which one or more) hydrogen atoms of a hydrocarbon are replaced by some other atoms (like chlorine), is called a substitution reaction.
Example: Substitution reaction of methane with chlorineMethane reacts with chlorine in the presence of sunlight to form chloromethane and hydrogen chloride.
$\text{CH}_4+\text{Cl}_2\xrightarrow[{}]{{ \ \ \ \ \ \ \ \ \ \ \ \text{Sunlight}}\ \ \ \ \ \ \ \\ }\text{CH}_3\text{Cl}+\text{HCl}$
Alkenes: C2H4, C3H6
Alkynes: C2H2, C3H4
Explanation:
C5H10O represents two organic compounds ketones (C2H5-CO-C2H5) and aldehydes (C2H5-CH2-CH2-CHO) which have different functional groups.
The functional group present in CH3CHO is the formyl group (-CHO).
The functional group present in CH3CH2COOH is the group of carboxylic acids (-COOH).
The functional group present in CH3COCH3 is the carbonyl group (-CO-).
The functional group present in CH3CH2CH2OH is the alcohol (hydroxyl) group (-OH).
