Physics M.C.Q (1 Marks)

X-rays · Jharkhand Board (JAC) STD 12 Science (Jharkhand - English Medium). 14 questions.

Questions

M.C.Q (1 Marks)

Take a timed test

14 questions · auto-graded multiple-choice test.

MCQ 11 Mark
The X-ray beam emerging from an X-ray tube:
  • A
    Is monochromatic.
  • B
    Has all wavelengths smaller than a certain maximum wavelength.
  • ✓
    Has all wavelengths greater than a certain minimum wavelength.
  • D
    Has all wavelengths lying between a minimum and a maximum wavelength.
Answer
Correct option: C.
Has all wavelengths greater than a certain minimum wavelength.
The X-ray beam emerging from an X-ray tube consists of wavelengths greater than a certain minimum wavelength called cutoff wavelength.
View full question & answer→
MCQ 21 Mark
50% of the X-ray coming from a Coolidge tube is able to pass through a 0.1mm thick aluminium foil. The potential difference between the target and the filament is increased. The thickness of the aluminium foil that will allow 50% of the X-ray to pass through will be:
  • A
    zero
  • B
    < 0.1mm
  • C
    0.1mm
  • ✓
    > 0.1mm
Answer
Correct option: D.
> 0.1mm
As we increase the accelerating potential between the filament and the target, the penetrating power of the X-ray will increase. As a result, the fraction of the X-ray passing through the foil will increase. But it is given that the same fraction of the X-ray is passing. Therefore, the thickness of the aluminium foil should be increased to maintain the same fraction of the X-ray that will pass through the foil.
View full question & answer→
MCQ 31 Mark
Visible light passing through a circular hole forms a diffraction disc of radius 0.1mm on a screen. If an X-ray is passed through the same setup, the radius of the diffraction disc will be:
  • A
    zero
  • ✓
    < 0.1mm
  • C
    0.1mm
  • D
    > 0.1m
Answer
Correct option: B.
< 0.1mm
Radius of the diffraction disc is directly proportional to the wavelength of the light used for the given hole. We know that the wavelength of an X-ray is less than the wavelength of visible light. If an X-ray is passed through the same setup, the radius of the diffraction disc will be less than 0.1m.
View full question & answer→
MCQ 41 Mark
One of the following wavelengths is absent and the rest are present in the X-rays coming from a Coolidge tube. Which one is the absent wavelength?
  • ✓
    25pm
  • B
    50pm
  • C
    75pm
  • D
    100pm
Answer
Correct option: A.
25pm
Cutoff wavelength (minimum) is absent in the X-rays coming from a Coolidge tube. Hence, the 25 pm wavelength is absent.
View full question & answer→
MCQ 51 Mark
Cutoff wavelength of $X-$rays coming from a Coolidge tube depends on the:
  • ✓
    Target material.
  • B
    Acelerating voltage.
  • C
    Separation between the target and the filament.
  • D
    Temperature of the filament.
Answer
Correct option: A.
Target material.
Cutoff wavelength $(\lambda_{\text{min}})$ is given by
$\lambda_{\text{min}}=\frac{\text{hc}}{\text{eV}}$
Here,
$h =$ Planck's constant
$c =$ Speed of light
$V =$ Accelerating voltage
$e =$ Charge of electron
Clearly, a cutoff wavelength depends on accelerating voltage. It does not depend on the target material, separation between the target and the temperature of the filament.
View full question & answer→
MCQ 61 Mark
​​​​50% of the X-rays coming from a Coolidge tube are able to pass through a 0.1mm thick aluminium foil. If the potential difference between the target and the filament is increased, the fraction of the X-rays passing through the same foil will be:
  • A
    0%
  • B
    < 50%
  • C
    50%
  • ✓
    > 50%
Answer
Correct option: D.
> 50%
The penetrating power of X-rays varies directly with the accelerating potential of the electrons (V) or the energy of the X-rays. So, if the potential difference between the target and the filament is increased, the fraction of the X-rays passing through the foil will also increase.
View full question & answer→
MCQ 71 Mark
Consider a photon of continuous X-ray and a photon of characteristic X-ray of the same wavelength. Which of the following is/are different for the two photons?
  • A
    Frequency.
  • B
    Energy.
  • C
    Penetrating power.
  • ✓
    Method of creation.
Answer
Correct option: D.
Method of creation.
Let $\lambda_1$ and $\lambda_2$ be the wavelengths of the photons of continuous and characteristic X-rays, respectively.
Given:
$\lambda_1=\lambda_2=\lambda$
Now, frequency $(\nu)$ is given by
$\nu=\frac{\text{c}}{\lambda_1}=\frac{\text{c}}{\lambda_2}$
$\Rightarrow\nu=\frac{\text{c}}{\lambda}$
Hence, the frequency of both the photons is the same.
Energy of a photon (E) is given by
$\text{E}=\text{h}\nu$
As the frequency of both the photons is the same, they will have the same energy.
The photon of the continuous X-ray and the photon of the characteristic X-ray consist of the same penetrating power.
The photon of the characteristic X-ray is created because of the transition of an electron from one shell to another. The photon of the continuous X-ray is created because of the conversion of the kinetic energy of an electron into a photon of electromagnetic radiation.
View full question & answer→
MCQ 81 Mark
$X-$ray from a Coolidge tube is incident on a thin aluminium foil. The intensity of the $X-$ray transmitted by the foil is found to be $I_0$. The heating current is increased to increase the temperature of the filament. The intensity of the $X-$ray transmitted by the foil will be:
  • A
    zero
  • B
    $< I_0$
  • C
    $I_0$
  • ✓
    $> I_0$
Answer
Correct option: D.
$> I_0$
We know that the intensity of an $X-$ray is directly proportional to the current through the $X-$ray tube. If the filament current is increased to increase the temperature of the filament, more electrons will be emitted from the filament per unit time. As a result, current in the $X-$ray tube will increase and consequently, the intensity of the $X-$ray will also increase.
View full question & answer→
MCQ 91 Mark
The figure shows the intensity-wavelength relations of $X -$rays coming from two different Coolidge tubes. The solid curve represents the relation for the tube A in which the potential difference between the target and the filament is $V_A$ and the atomic number of the target material is $Z_A$. These quantities are $V_B$ and $Z_B$ for the other tube. Then:
  • A
    $V_A > V_B, Z_A > Z_B$

  • ✓
    $V_A > V_B, Z_A < Z_B$

  • C
    $V_A < V_B, Z_A > Z_B$

  • D
    $V_A > V_B, Z_A < Z_B$
Answer
Correct option: B.
$V_A > V_B, Z_A < Z_B$


It is clear from the figure that the $ X-$ray of tube A has less cutoff wavelength than the $ X-$ray of tube $B.$
$\therefore\lambda_\text{A}<\lambda_\text{B}$
Using Moseley's Law,
$Z_A < Z_B$
$\lambda\propto\frac{1}{\text{V}}$, where $V$ is the voltage applied in the $ X-$ray tube.
$\therefore$ $ V_a > V_B$

View full question & answer→
MCQ 101 Mark
Consider a photon of a continuous X-ray coming from a Coolidge tube. Its energy comes from:
  • ✓
    The kinetic energy of the striking electron.
  • B
    The kinetic energy of the free electrons of the target.
  • C
    The kinetic energy of the ions of the target.
  • D
    An atomic transition in the target.
Answer
Correct option: A.
The kinetic energy of the striking electron.
In an X-ray tube, electrons are emitted by the filament when it is heated. An electric field generated by a DC battery between the filament and the target makes the electrons hit the target atoms with a very high speed. As a result, the electrons lose their kinetic energy to eject photons, which leads to a continuous emission of X-rays.
View full question & answer→
MCQ 111 Mark
X-ray beam can be deflected:
  • A
    By an electric field.
  • B
    By a magnetic field.
  • C
    By an electric field as well aa by a magnetic field.
  • ✓
    Neither by an electric field nor by a magnetic field.
Answer
Correct option: D.
Neither by an electric field nor by a magnetic field.
Since X-rays do not have any charged particles, they are not deflected by an electric field or a magnetic field.
View full question & answer→
MCQ 121 Mark
If the current in the circuit for heating the filament is increased, the cutoff wavelength:
  • A
    Will increase.
  • B
    Will decrease.
  • ✓
    Will remain unchanged.
  • D
    Will change.
Answer
Correct option: C.
Will remain unchanged.
Cut off wavelength is given by
$\lambda_\text{min}=\frac{\text{hc}}{\text{eV}'}$
where h = Planck's constant
c = speed of light
e = charge on an electron
V = potential difference applied to the tube
Clearly, the cutoff wavelength does not depend on the current in the circuit and temperature of the filament.
View full question & answer→
MCQ 131 Mark
The energy of a photon of a characteristic X-ray from a Coolidge tube comes from:
  • A
    The kinetic energy of the striking electron.
  • B
    The kinetic energy of the free electrons of the target.
  • C
    The kinetic energy of the ions of the target.
  • ✓
    An atomic transition in the target.
Answer
Correct option: D.
An atomic transition in the target.
In an X-ray tube, electrons are emitted by the filament. These electrons are made to strike the filament by applying an electric field between the filament and the target. As a result of it, the kinetic energy of the electrons is lost to the target atoms. This energy is utilised by the target atoms to knock out an electron from the innermost shell. Consequently, the electron makes a transition from the higher energy state to this vacant shell. Due to this transition, the difference of energy of the two states gives photon of characteristic X-ray.
View full question & answer→
MCQ 141 Mark
If the potential difference applied to the tube is doubled and the separation between the filament and the target is also doubled, the cutoff wavelength:
  • A
    Will remain unchanged.
  • B
    Will be doubled.
  • ✓
    Will be halved.
  • D
    Will become four times the original.
Answer
Correct option: C.
Will be halved.
Cut off wavelength is given by
$\lambda_{\text{min}}=\frac{\text{hc}}{\text{eV}'}$

where h = Planck's constan

c = speed of light

e = charge on an electron

V = potential difference applied to the tube

When potential difference (V) applied to the tube is doubled, cutoff wavelength

$\big({\lambda}'_\text{min}\big)$ is given by

${\lambda}'_\text{min}=\frac{\text{hc}}{\text{e}(2\text{V})}$

$\Rightarrow\lambda'_\text{min}=\frac{\lambda_\text{min}}{2}$

Cuttoff wavelength does not depend on the separation between the filament and the target.

Thus, cutoff wavelength will be halved if the the potential difference applied to the tube is doubled.
View full question & answer→
