MCQ
A cell having an emf $\varepsilon$ and internal resistance $r$ is connected across a variable external resistance $R.$ As the resistance $R$ is increased, the plot of potential difference $V$ across $R$ is given by
- A
- B
- ✓
- D
✓
Answer
Correct option: C.
c
Current in the circuit, $I=\frac{\varepsilon}{R+r}$
Current in the circuit, $I=\frac{\varepsilon}{R+r}$
Potential difference across $R$
${V=I R=\left(\frac{\varepsilon}{R+r}\right) R} $
${V=\frac{\varepsilon}{1+\frac{r}{R}}}$
When $R=0, V=0$
$R=\infty, V=\varepsilon$
Need a full question paper?
Generate a complete, print-ready paper with questions like this in minutes — across 16+ boards, with answer keys.
Explore more
Similar questions
A block having mass $m$ collides with an another stationary block having mass $2\,m$. The lighter block comes to rest after collision. If the velocity of first block is $v$, then the value of coefficient of restitution will must be
→The frequency of $K_{\alpha} , K_{\beta}$ and $L_{\alpha}$ $X-$ rays of a material are $\gamma _1, \gamma _2$ and $\gamma _3 $ respectively. Which of the following relations holds good ?
→Gas at a pressure ${P_0}$ in contained is a vessel. If the masses of all the molecules are halved and their speeds are doubled, the resulting pressure $P$ will be equal to
→Carefully analyses the diagram and choose the correct option :
