Question

A wire having linear density of 0.05 gcm^-1 is stretched between two rigid supports with a tension of 4.5 × 10⁷ dynes. It is observed that me wire resonates at a frequency of 420Hz. The next higher frequency at which the wire resonates is 490Hz. Find the length of the wire.

✓

Answer

Let 420Hz be the pth harmonic, then 490Hz is the (p + 1)th harmonic.
Therefore,
$420=\frac{\text{p}}{2\text{L}}\sqrt{\frac{\text{T}}{\text{m}}}\ \dots(\text{i})$
$\therefore490=\frac{\text{p}+1}{2\text{L}}\sqrt{\frac{\text{T}}{\text{m}}}\ \dots(\text{ii})$
Dividing (ii) by (i), we get
$\frac{490}{420}=\frac{\text{p}+1}{\text{p}}$
$\Rightarrow \text{p}=6.$
Substituting this value of P in eqn. (i), we get
$420=\frac{6}{2\text{L}}\times \sqrt{\frac{4.5\times10^7}{0.05}}$
which give $\text{L}=214.3\text{cm}$

Need a full question paper?

Generate a complete, print-ready paper with questions like this in minutes — across 16+ boards, with answer keys.

Start Generating Free

Explore more

More "3 Marks Question" from Waves→Waves — all question types→Physics STD 11 Science question papers→Rajasthan Board STD 11 Science question papers→Rajasthan Board question paper generator→

Similar questions

Identify the types of motion in following cases:

A rod of mass m and length L, lying horizontally, is free to rotate about a vertical axis through its centre. A horizontal force of constant magnitude F acts on the rod at a distance of $\frac{\text{L}}{4}$ from the centre. The force is always perpendicular to the rod. Find the angle rotated by the rod during the time (t) after the motion starts.

A vertical off-shore structure is built to withstand a maximum stress of 109 Pa. Is the structure suitable for putting up on top of an oil well in the ocean? Take the depth of the ocean to be roughly 3km, and ignore ocean currents.

The gravitational potential energy of a two particle system is derived in this chapter as $\text{U}=-\frac{\text{Gm}_1\text{m}_2}{\text{r}}.$ Does it follow from this equation that the potential energy for $\text{r}=\infty$ must be zero? Can we choose the potential energy for $\text{r}=\infty.$ to be 20J and still use this formula? If no, what formula should be used to calculate the gravitational potential energy at separation r?

In a p-n junction, a potential barrier of 250meV exists across the junction. A hole with a kinetic energy of 300meV approaches the junction. Find the kinetic energy of the hole when it crosses the junction if the hole approached the junction.

From the p-side.
From the n-side.

Consider the situation of the previous problem. Find the average electric field energy stored in the capacitor and the average magnetic field energy stored in the coil.

A thin prism of crown glass $(\mu_\text{r}=1.515,\mu_\text{v}=1.525)$ and a thin prism of flint glass $(\mu_\text{r}=1.612,\mu_\text{v}=1.632)$ are placed in contact with each other. Their refracting angles are 5.0° each and are similarly directed. Calculate the angular dispersion produced by the combination.

The voltage and current in a series AC circuit are given by, $\text{V}=\text{V}_0\cos\omega\text{t}$ and $\text{i}=\text{i}_0\sin\omega\text{t}.$ What is the power dissipated in the circuit?

Derive an expression for the excess of pressure inside a liquid drop.

Find the angular velocity for an object to experience weightlessness at the equator of earth. Under this condition, also find the duration of a day.
