An object is placed between infinity and the pole of a convex mirror. Draw a ray diagram and also state the position, the relative size and the nature of the image formed.
CBSE OUTSIDE DELHI - SET 1 2011
Download our app for free and get started
Position of image: Between P and F, behind the mirror.Size: Diminished.
Nature of the image: Virtual and erect.
