What is the magnification produced by a rear view mirror fitted in vehicles?

Draw ray diagrams showing the image formation by a concave mirror when an object is placed:
Between pole and focus of the mirror.

What is the difference between a real image and a virtual image? Give one example of each type of image.

State one practical application the use of such a lens with the object in position (i) and (ii).

Explain with a suitable diagram, how a concave mirror converges a parallel beam of light rays. Mark clearly the pole, focus and centre of curvature of concave mirror in this diagram.

A student focuses the image of a well illuminated distant object on a screen using a convex lens. After that he gradually moves the object towards the lens and each time focuses its image on the screen by adjusting the lens.

1. In which direction-towards the screen or away from the screen, does he move the lens?
2. What happens to the size of the image-does it decrease or increase?
3. What happens to the image on the screen when he moves the object very close to the lens?

What is observed when 2mL of dilute hydrochloric acid is added to 1g of sodium carbonate taken in a clean and dry test tube? Write chemical equation for the reaction involved.

State three characteristics of the image formed by a convex mirror.

1. Find the nature, position and magnification of the images formed by a convex lens of focal length 0.20 m if the object is placed at a distance of:

1. 0.50m
2. 0.25m
3. 0.15m

2. Which of the above cases represents the use of convex lens in a film projector, in a camera, and as a magnifying glass?

Identify the device used as a spherical mirror or lens in following cases, when the image formed is virtual and erect in each case.Object is placed between infinity and device, image formed is diminished and between focus and optical centre on the same side as that of the object.
