Question
In a $\triangle\text{ABC},$ it is given that $\angle\text{A}:\angle\text{B}:\angle\text{C}=3:2:1$ and $\text{CD}\perp\text{AC}.$ Find $\angle\text{ECD}.$
✓
Answer
In the given $\triangle\text{ABC},$ we have,$\angle\text{A}:\angle\text{B}:\angle\text{C}=3:2:1$
Let $\angle\text{A}=3\text{x},\angle\text{B}=2\text{x},\angle\text{C}=\text{x}.$ Then,$\angle\text{A}+\angle\text{B}+\angle\text{C}=180^\circ$
$\Rightarrow3\text{x}+2\text{x}+\text{x}=180^\circ$
$\Rightarrow6\text{x}=180^\circ$
$\Rightarrow\text{x}=30^\circ$
$\therefore\angle\text{A}=3\text{x}=3\times30^\circ=90^\circ$
$\angle\text{B}=2\text{x}=2\times30^\circ=60^\circ$
and $\angle\text{C}=\text{x}=30^\circ$ Now, in ABC, we have, Ext. $\angle\text{ACE}=\angle\text{A}+\angle\text{B}=90^\circ+60^\circ=150^\circ$$\therefore\angle\text{ACD}+\angle\text{ECD}=150^\circ$
$\Rightarrow\angle\text{ECD}=150^\circ-\angle\text{ACD}$
$\Rightarrow\angle\text{ECD}=150^\circ-90^\circ$ $\big[\text{since}\ \text{AD}\perp\text{CD},\ \angle\text{ACD}=90^\circ\big]$
$\Rightarrow\angle\text{ECD}=60^\circ$
Let $\angle\text{A}=3\text{x},\angle\text{B}=2\text{x},\angle\text{C}=\text{x}.$ Then,$\angle\text{A}+\angle\text{B}+\angle\text{C}=180^\circ$
$\Rightarrow3\text{x}+2\text{x}+\text{x}=180^\circ$
$\Rightarrow6\text{x}=180^\circ$
$\Rightarrow\text{x}=30^\circ$
$\therefore\angle\text{A}=3\text{x}=3\times30^\circ=90^\circ$
$\angle\text{B}=2\text{x}=2\times30^\circ=60^\circ$
and $\angle\text{C}=\text{x}=30^\circ$ Now, in ABC, we have, Ext. $\angle\text{ACE}=\angle\text{A}+\angle\text{B}=90^\circ+60^\circ=150^\circ$$\therefore\angle\text{ACD}+\angle\text{ECD}=150^\circ$
$\Rightarrow\angle\text{ECD}=150^\circ-\angle\text{ACD}$
$\Rightarrow\angle\text{ECD}=150^\circ-90^\circ$ $\big[\text{since}\ \text{AD}\perp\text{CD},\ \angle\text{ACD}=90^\circ\big]$
$\Rightarrow\angle\text{ECD}=60^\circ$
Need a full question paper?
Generate a complete, print-ready paper with questions like this in minutes — across 16+ boards, with answer keys.
Explore more
Similar questions
In Q.No. 7, what is the probability of getting at least two heads?
By using data in example (6), and taking classes 30 – 40, 40 – 50,… prepare equal to or more than type cumulative frequency table and answer the following questions based on it.
i. How many students have scored marks 70 or more than 70?
ii. How many students have scored marks 30 or more than 30?
i. How many students have scored marks 70 or more than 70?
ii. How many students have scored marks 30 or more than 30?
$2x^4 - 7x^3 - 13x^2 + 63x - 45$
→A hollow garden roller, 63cm wide with a girth of 440cm, is made of 4cm thick iron. Find the volume of the iron.
Find the values of x and y using the information shown in the given figure. Find the measures of ∠ABD and ∠ACD.
The given figure shows a pentagon ABCDE. EG, drawn parallel to DA, meets BA produced at G, and CF, drawn parallel to DB, meets AB produced at F. Show that:
