Question
In the adjoining figure, $\text{BM}\perp\text{AC}$ and $\text{DN}\perp\text{AC}.$ If BM = DN, prove that AC bisects BD.
✓
Answer
Given: A quadrilateral ABCD, in which $\text{BM}\perp\text{AC}$ and $\text{DN}\perp\text{AC}$ and BM = DN. To prove: AC bisects BD; or DO = BO Proof: Let AC and BD intersect at O. Now, in $\triangle\text{OND}$ and $\triangle\text{OMB},$ we have:$\angle\text{OND}=\angle\text{OMB}$ (90° each)
$\angle\text{DON}=\angle\text{BOM}$ (Vertically opposite angles)
Also, $\text{DN = BM}$ (Given) i.e., $\triangle\text{OND}\cong\triangle\text{OMB}$ (AAS congrurence rule)$\therefore\text{OD = OB}$ (C.P.C.T.)
Hence, AC bisects BD.
$\angle\text{DON}=\angle\text{BOM}$ (Vertically opposite angles)
Also, $\text{DN = BM}$ (Given) i.e., $\triangle\text{OND}\cong\triangle\text{OMB}$ (AAS congrurence rule)$\therefore\text{OD = OB}$ (C.P.C.T.)
Hence, AC bisects BD.
Need a full question paper?
Generate a complete, print-ready paper with questions like this in minutes — across 16+ boards, with answer keys.
Explore more
Similar questions
A wooden bookshelf has external dimensions as follows:
Height $=110 cm$, Depth $=25 cm$, Breadth $=85 cm$ (See figure).
The thickness of the plank is 5 cm everywhere.
The external faces are to be polished and the inner faces are to be painted.
If the rate of polishing is 20 paise per $cm ^2$.
Find the total expenses required for polishing and painting the surface of the bookshelf.
→Height $=110 cm$, Depth $=25 cm$, Breadth $=85 cm$ (See figure).
The thickness of the plank is 5 cm everywhere.
The external faces are to be polished and the inner faces are to be painted.
If the rate of polishing is 20 paise per $cm ^2$.
Find the total expenses required for polishing and painting the surface of the bookshelf.
Write the following polynomials in coefficient form.
i. $x^3-2$
ii. $5 y$
iii. $2 m^4-3 m^2+7$
iv. $-\frac{2}{3}$
→i. $x^3-2$
ii. $5 y$
iii. $2 m^4-3 m^2+7$
iv. $-\frac{2}{3}$
If the polynomials $a x^3+3 x^2-13$ and $2 x^3-5 x+a$, when divided by $(x-2)$ leave the same remainder, Find the value of $a$.
→Represent $\sqrt{10.5}$ on the number line.
→Solve the following equations:$8^{\text{x}+1}=16^{\text{y}+2}$ and $\Big(\frac{1}{2}\Big)^{3+\text{x}}=\Big(\frac{1}{4}\Big)^{3\text{y}}$
→In the adjoining figure, ABCD is a trapezium in which AB || DC; AB = 7cm; AD = BC = 5cm and the distance between AB and DC is 4cm. Find the length of DC and hence, find the area of trap. ABCD.
In an isosceles triangle, if the vertex angle is twice the sum of the base angles, calculate the angles of the triangle.
A wooden toy is in the form of a cone surmounted on a hemisphere. The diameter of the base of the cone is $16cm$ and its height is $15cm.$
Find the cost of painting the toy at $Rs. 7$ per $100cm^2$
→Find the cost of painting the toy at $Rs. 7$ per $100cm^2$
In the figure given below, AB || CD. Find the value of x in each case.
The following data gives the number (in thousands) of applicants registered with an Employment Exchange during 1995–2000:
Construct a bar graph to represent the above data.
|
Year
|
1995
|
1996
|
1997
|
1998
|
1999
|
2000
|
|
Number of Applicants Registered (in thousands)
|
18
|
20
|
24
|
28
|
30
|
34
|
