Wave Optics — Physics STD 12 Science — Question

Gujarat BoardEnglish MediumSTD 12 SciencePhysicsWave Optics1 Mark
MCQ
In Young's double slit experiment, the interference pattern obtained with white light will be:
  • A
    The central fringe bright and alternate bright and dark fringes.
  • ✓
    The central fringe achromatic and coloured fringes for small path difference.
  • C
    The central fringe dark
  • D
    The central fringe coloured
✓

Answer

Correct option: B.
The central fringe achromatic and coloured fringes for small path difference.

If white light is used a white centre fringe is observed, but all the other fringes have coloured edges, the blue edge being nearer the centre. Eventually the fringes overlap and a uniform white light is produced.

Need a full question paper?

Generate a complete, print-ready paper with questions like this in minutes — across 16+ boards, with answer keys.

Start Generating Free

Explore more

More "M.C.Q (1 Marks)" from Wave Optics→Wave Optics — all question types→Physics STD 12 Science question papers→Gujarat Board STD 12 Science question papers→Gujarat Board question paper generator→

Similar questions

A proton (mass m and charge +e) and an α - particle (mass 4m and charge +2e) are projected with the same kinetic energy at right angles to the uniform magnetic field. Which one of the following statements will be true
→
A ray $\mathrm{OP}$ of monochromatic light is incident on the face $\mathrm{AB}$ of prism $\mathrm{ABCD}$ near vertex $\mathrm{B}$ at an incident angle of $60^{\circ}$ (see figure). If the refractive index of the material of the prism is $\sqrt{3}$, which of the following is (are) correct? $Image$

$(A)$ The ray gets totally internally reflected at face $CD$

$(B)$ The ray comes out through face $\mathrm{AD}$

$(C)$ The angle between the incident ray and the emergent ray is $90^{\circ}$

$(D)$ The angle between the incident ray and the emergent ray is $120^{\circ}$

→
A wire $X$ of length $50\; cm$ carrying a current of $2\,A$ is placed parallel to a long wire $Y$ of length $5\,m$. The wire $Y$ carries a current of $3\,A$. The distance between two wires is $5\,cm$ and currents flow in the same direction. The force acting on the wire $Y$ is.
→
A glass prism of refractive index $1.5$ is immersed in water (refractive index $\frac {4}{3}$ ) as shown in figure. A light beam incident normally on the face $AB$ is totally reflected to reach the face $BC,$ if
→
A light ray is incident by grazing one of the face of a prism and after refraction ray does not emerge out, what should be the angle of prism while critical angle is $C$
→
A circular disc $A$ of radius r is made from an iron plate of thickness $(t)$ and another circular disc $B$ of radius $4r$ is made from an iron plate of thickness $\frac{\text{t}}{4}.$ The relation between the moments of inertia $I_A$ and $I_B$ is:
→
The distance between the circular plates of a parallel plate condenser $40\,mm$ in diameter, in order to have same capacity as a sphere of radius $1\;metre$ is....$mm$
→
When a potential difference is applied across, the current passing through
→
Match List $I$ with List $II$ and select the correct answer using the codes given below the lists :

List $I$

(Position of the object)

List $II$

(Magnification)

$(I)$ An object is placed at focus before a convex mirror

$(A)$ Magnification is $-\infty$

$(II)$ An object is placed at centre of curvature before a concave mirror

$(B)$ Magnification is $0.5$

$(III)$ An object is placed at focus before a concave mirror

$(C)$ Magnification is $+1$

$(IV)$ An object is placed at centre of curvature before a convex mirror

$(D)$ Magnification is $-1$



$(E)$ Magnification is $0.33$
→
A potentiometer consists of a wire of length $4\, m$ and resistance $10 \,\Omega$. It is connected to cell of $emf$ $2\, V$. The potential difference per unit length of the wire will be ............ $V/m$
→
