Question
Obtain the angular magnification for the image formed at infinity for simple microscope.
✓
Answer
→When an object of height $h$ is placed at the near point as shown in the figure (a), the angle subtended at the eye by the object is $\theta_0$.
→from figure, $\tan \theta_0=\frac{h}{ D }$
for small angle, $\tan \theta_0 \approx \theta_0=\frac{h}{ D }......(1)$
→As shown in figure (b), if an object of height $h$ is placed at the principal focus, its image will be at an infinite distance. This time, the angle subtended at the eye by the object is $\theta_i$.
→from figure, $\tan \theta_i=\frac{h}{f}$
but for small angle, $\tan \theta_i \approx \theta_i=\frac{h}{f}......(2)$
→angular magnification of lens,
$\begin{aligned}m & =\frac{\theta_i}{\theta_0}=\frac{\frac{h}{f}}{\frac{h}{ D }}=\frac{h}{f} \times \frac{ D }{h} \\\therefore m & =\frac{ D }{f}\end{aligned}$
→This is the magnification when the image is at infinity.
→Thus, the magnification obtained with simple microscope is between $\frac{ D }{f}$ to $1+\frac{ D }{f}$.
Need a full question paper?
Generate a complete, print-ready paper with questions like this in minutes — across 16+ boards, with answer keys.
Explore more
Similar questions
Define the term ‘linearly polarised light’.
When’ does the intensity of transmitted light become maximum, when a polaroid sheet is rotated between two crossed polaroids?
When’ does the intensity of transmitted light become maximum, when a polaroid sheet is rotated between two crossed polaroids?
A ball is thrown vertically upward with a speed of 20m/s. Draw a graph showing the velocity of the ball as a function of time as it goes up and then comes back.
Length of a metallic wire is 1 m and its area of cross-section is A square meters. If this wire is stretched to double its length, then by how much percent will its resistance increase?
Use Lenz’s law to determine the direction of induced current in the situations described by Fig.
