The figure shows a circuit having eight resistances of $1 \Omega$ each, labelled $R_1$ to $R_8$, and two ideal batteries with voltages $\varepsilon_1=12 V$ and $\varepsilon_2=6 V$.

Which of the following statement($s$) is(are) correct?

$(A)$ The magnitude of current flowing through $R_1$ is $7.2 A$.

$(B)$ The magnitude of current flowing through $R_2$ is $1.2 A$.

$(C)$ The magnitude of current flowing through $R_3$ is $4.8 A$.

$(D)$ The magnitude of current flowing through $R_5$ is $2.4 A$.

  • A$A,B,C$
  • B$A,B,D$
  • C$A,B,C$
  • D$A,B,C,D$
IIT 2022, Advanced
