Sample Questions

Heat Transfer questions

One sample from each question group in this chapter. Select any group above to see the full set with answer keys.

Q 1M.C.Q (1 Marks)1 Mark
One end of a metal rod is dipped in boiling water and the other is dipped in melting ice:
  • A
    All parts of the rod are in thermal equilibrium with each other.
  • B
    We can assign a temperature to the rod.
  • C
    We can assign a temperature to the rod after steady state is reached.
  • ✓
    The state of the rod does not change after steady state is reached.

Answer: D.

View full solution →
Q 3M.C.Q (1 Marks)1 Mark
In a room containing air, heat can go from one place to another:
  • A
    By conduction only.
  • B
    By convection only.
  • C
    By radiation only.
  • ✓
    By all the three modes.

Answer: D.

View full solution →
Q 5M.C.Q (1 Marks)1 Mark
One end of a metal rod is kept in a furnace. In steady state, the temperature of the rod:
  • A
    Increases.
  • B
    Decreases.
  • C
    Remains constant.
  • ✓
    Is nonuniform.

Answer: D.

View full solution →
Q 61 Marks Question1 Mark
Standing in the sun is more pleasant on a cold winter day than standing in shade. Is the temperature of air in the sun considerably higher than that of the air in shade?
View full solution →
Q 71 Marks Question1 Mark
The temperature of the atmosphere at a high altitude is around $500^{\circ} \mathrm{C}$. Yet an animal there would freeze to death and not boil. Explain.
View full solution →
Q 81 Marks Question1 Mark
Assume that the total surface area of a human body is $1.6m^2$ and that it radiates like an ideal radiator. Calculate the amount of energy radiated per second by the body if the body temperature is $37^\circ$ C. Stefan constant $\sigma$ is $6.0 × 10^{-8}  Wm ^{-2}K^{-4}$.
View full solution →
Q 92 Marks Questions2 Marks
On a cold winter night you are asked to sit on a chair. Would you like to choose a metal chair or a wooden chair? Both are kept in the same lawn and are at the same temperature.
View full solution →
Q 132 Marks Questions2 Marks
Calculate the amount of heat radiated per second by a body of surface area $12cm^2$ kept in thermal equilibrium in a room at temperature $20^\circ C.$ The emissivity of the surface = 0.80 and $\sigma=6.0\times10^{-8}\text{Wm}^{-2}\text{K}^{-4}.$
View full solution →
Q 143 Marks Question3 Marks
Water is boiled in a container having a bottom of surface area $25cm^2$, thickness 1.0mm and thermal conductivity $50\text{wm}^{-1}{^{\circ}}\text{C}^{-1}.$ 100g of water is converted into steam per minute in the steady state after the boiling starts. Assuming that no heat is lost to the atmosphere, calculate the temperature of the lower surface of the bottom. Latent heat of vaporization of water $=0.26\times10^6\text{Jkg}^{-1}.$
View full solution →
Q 163 Marks Question3 Marks
The ends of a metre stick a.re maintained at 100°C and 0°C. One end of a rod is maintained at 25°C. Where should its other end be touched on the metre stick so that there is no heat current in the rod in steady state?
View full solution →
Q 173 Marks Question3 Marks
A cylindrical rod of length 50cm and cross sectional area $1cm^2$ is fitted between a large ice chamber at 0°C and an evacuated chamber maintained at 27°C as shown in figure. Only small portions of the rod are inside the chambers and the rest is thermally insulated from the surrounding. The cross section going into the evacuated chamber is blackened so that it completely absorbs any radiation falling on it. The temperature of the blackened end is 17°C when steady state is reached. Stefan constant $\sigma=6\times10^{-8}\text{W/m}^{-2}\text{K}^{-4}.$ Find the thermal conductivity of the material of the rod.
View full solution →
Q 183 Marks Question3 Marks
A cubical box of volume $216cm^3$ is made up of 0.1cm thick wood. The inside is heated electrically by a 100W heater. It is found that the temperature difference between the inside and the outside surface is 5°C in steady state. Assuming that the entire electrical energy spent appears as heat, find the thermal conductivity of the material of the box.
View full solution →
Q 195 Marks Questions5 Marks
A spherical tungsten piece of radius 1.0cm is suspended in an evacuated chamber maintained at 300K. The piece is maintained at 1000K by heating it electrically. Find the rate at which the electrical energy must be supplied. The emissivity of tungsten is 0.30 and the Stefan constant $\sigma$ is $6.0 \times 10^{-8}Wm^{-2}K^{-4}.$
View full solution →
Q 205 Marks Questions5 Marks
A calorimeter contains 50g of water at $50^\circ C$. The temperature falls to $45^\circ C$ in 10 minutes. When the calorimeter contains 100g of water·at $50^\circ 0$, it takes 18 minutes for the temperature to become $45^\circ C$. Find the water equivalent of the calorimeter.
View full solution →
Q 215 Marks Questions5 Marks
Seven rods A, B, C, D, E, F and G are joined as shown in figure. All the rods have equal cross-sectional area A and length l. The thermal conductivities of the rods are $K_A = K_c = K_0, K_B = K_D = 2K_0, K_E= 3K_{0,} K_F = 4K_0,$ and $K_G = 5K_0.$ The rod E is kept at a constant temperature $T_2$ and the rod G is kept at a constant temperature $T_2(T_2 > T_1).$
  1. Show that the rod F has a uniform temperature $\text{T}=\frac{(\text{T}_1+2\text{T}_2)}{3}.$
  2. Find the rate of heat flowing from the source which maintains the temperature $T_2.$
View full solution →
Q 225 Marks Questions5 Marks
An icebox almost completely filled with ice at 0°C is dipped into a large volume of water at 20°C. The box has walls of surface area $2400cm^2,$ thickness 2.0mm and thermal conductivity $0.06\text{Wm}^{-1}{^{\circ}}\text{C}^{-1}.$ Calculate the rate at which the ice melts in the box. Latent heat of fusion of ice $= 3.4\times10^5\text{Jkg}^{-1}.$
View full solution →
Q 235 Marks Questions5 Marks
A steel frame $(\text{K}=45\text{Wm}^{-1}{^{\circ}}\text{C}^{-1})$of total length 60cm and cross sectional area $0.20cm^2,$ forms three sides of a square. The free ends are maintained at 20°C and 40°C. Find the rate of heat flow through a cross section of the frame.
View full solution →
Q 24Case study (4 Marks)4 Marks
Suppose the bent part of the frame of the previous problem has a thermal conductivity of ${780Js^{-1}m^{-1}}^\circ C^{-1}$ whereas it is ${390Js^{-1}m^{-1}}^\circ C^{-1}$ for the straight part. Calculate the ratio of the rate of heat flow through the bent part to the rate of heat flow through the straight part.
View full solution →
Q 26Case study (4 Marks)4 Marks
Consider the situation shown in figure. The frame is made of the same material and has a uniform cross-sectional area everywhere. Calculate the amount of heat flowing per second through a cross section of the bent part if the total heat taken out per second from the end at 100°C is 130J.
View full solution →
Q 27Case study (4 Marks)4 Marks
The three rods shown in figure, have identical geometrical dimensions. Heat flows from the hot end at a rate of 40 Win the arrangement (a) Find the rates of heat flow when the rods are joined as in arrangement (b) and in (c) Thermal conductivities of aluminium and copper are ${200Wm^{-1}}^\circ C^{-1}$ and ${400Wm^{-1}}^\circ C^{-1}$ respectively.
  1.
  1.
  1.
View full solution →
Q 28Case study (4 Marks)4 Marks
An amount n (in moles) of a monatomic gas at an initial temperature $T_0$ is enclosed in a cylindrical vessel fitted with a light piston. The surrounding air has a temperature $T_s(> T_0)$ and the atmospheric pressure is $P_a.$ Heat may be conducted between the surrounding and the gas through the bottom of the cylinder. The bottom has a surface area A, thickness x and thermal conductivity K. Assuming all changes to be slow, find the distance moved by the piston in time t.
View full solution →
