In the connections shown in the adjoining figure, the equivalent capacity between $A$ and $B$ will be......$\mu F$
Medium
Download our app for free and get started
(d) Given circuit can be drawn as follows. It is a balance whetstone bridge type network, hence $24\, µF$ capacitor can be neglected
Equivalent capacitance between $A$ and $B$ $= 4 + 6 = 10\,µF$.
