Which of the following are concave mirrors and which convex mirrors?
Shaving mirrors, Car headlight mirror, Searchlight mirror, Driving mirror, Dentist’s inspection mirror, Torch mirror, Staircase mirror in a double-decker bus, Make-up mirror, Solar furnace mirror, Satellite TV dish, Shop security mirror.

An object is kept at a distance of 100cm from each of the above lenses. Calculate the (i) image distance and (ii) magnification in each of the two cases.

An object is placed at a distance equal to 2f in front of a convex lens. Draw a labelled ray diagram to show the formation of image. State two characteristics of the image formed.

Describe an activity to show that the colours of white light splinted by a glass prism can be recombined to get white light by another identical glass prism. AIso draw ray diagram to show the recombination of the spectrum of white light.

Explain why, a stick half immersed in water appears to be bent at the surface. Draw a labelled diagram to illustrate your answer.

A shop security mirror 5.0m from certain items displayed in the shop produces one-tenth magnification.

1. What is the type of mirror?
2. What is the radius of curvature of the mirror?

An object 2cm tall stands on the principal axis of a converging lens of focal length 8cm. Find the position, nature and size of the image formed if the object is:

1. 12cm from the lens.
2. 6 cm from the lens.

What is the difference between regular reflection of light and diffuse reflection of light? What type of reflection of light takes place from:

1. A cinema screen.
2. A plane mirror.
3. A cardboard.
4. Still water surface of a lake

A 2.0cm tall object is place perpendicular to the principal axis of a concave lens of focal length 15cm. At what distance from the lens, should the object be placed so that it forms an image 10cm from the lens? Also find the nature and the size of image formed.
