Structure of Atom — Chemistry STD 11 Science — Question

Rajasthan BoardEnglish MediumSTD 11 ScienceChemistryStructure of Atom3 Marks
Question
The first shell may contain up to 2 electrons, the second shell up to 8, the third shell up to 18, and the fourth shell up to 32. Explain this arrangement in terms of quantum numbers.
✓

Answer

For the fust shell $\text{n}=1,\text{l}=0,\text{m}_\text{l}=0,\text{m}_\text{s}=+\frac{1}{2}$ and $-\frac{1}{2}.$ It can have 2 electrons both with opposite spins.

  1. For $\text{n}=2,$

$\text{l}=0,\text{m}_\text{l}=0,\text{m}_\text{s}=+\frac{1}{2},-\frac{1}{2},$

$\text{l}=1,\text{m}_\text{l}=1,0+1,\text{m}_\text{s}=+\frac{1}{2},-\frac{1}{2}.$

Therefore, a total of 2 + 6 = 8 electrons are present.

  1. For $\text{n}=3,$ when

$\text{l}=0,\text{m}_\text{l}=0,\text{m}_\text{s}=+\frac{1}{2},-\frac{1}{2}$

$\text{l}=1,\text{m}_\text{l}=-1,0+1,\text{m}_\text{s}=\frac{1}{2},-\frac{1}{2}$

$\text{l}=2,\text{m}_\text{l}=-2,-1,0,+1,+2,,\text{m}_\text{s}$

$=+\frac{1}{2},-\frac{1}{2}$

Therefore, a total of 2 + 6 + 10 = 18 electlons aie present.

  1. For $\text{n}=4,$ when

$\text{l}=0,\text{m}_\text{l}=0,\text{m}_\text{s}=+\frac{1}{2},-\frac{1}{2}$

$\text{l}=1,\text{m}_\text{l}=-1,0+1,\text{m}_\text{s}=+\frac{1}{2},-\frac{1}{2}$

$\text{l}=3,\text{m}_\text{l}=-2,-1,0+1,+2,\text{m}_\text{s}=+\frac{1}{2},-\frac{1}{2}$

$\text{l}=3,\text{m}_\text{l}=-3,-2,-1,0,+1,+2,+3,\text{m}_\text{s}$

$=+\frac{1}{2},-\frac{1}{2}$

Therefore, a total of 2 + 6 + 10 + 14 = 32 electrons are present.

Need a full question paper?

Generate a complete, print-ready paper with questions like this in minutes — across 16+ boards, with answer keys.

Start Generating Free

Explore more

More "3 Marks Question" from Structure of Atom→Structure of Atom — all question types→Chemistry STD 11 Science question papers→Rajasthan Board STD 11 Science question papers→Rajasthan Board question paper generator→

Similar questions

What do you understand by exothermic reaction and endothermic reaction? Give one example of each type.
→
The following techniques are used to quantitatively estimate extra elements in organic compound. Identify the name of the method and the element estimated by this method.
  1. A known mass of an organic compound is heated with fuming HNO3 in presence of AgNO3.
  2. Organic compound is heated with dry copper oxide in atmosphere of CO2.
  3. Organic compound is heated with conc. H2SO4.
→
The diameter of zinc atom is 2.6 $\mathring{\text{A}}$.Calculate,
  1. Radius of zinc atom in pm
  2. Number of atoms present in a length of 1.6cm if the zinc atoms are arranged side by side lengthwise.
→
An alkyl halide (X) of formula C3H13Cl on treatment with alcoholic KOH or potassium tert-butoxide gives two isomeric alkenes Yand Z(C6H12). Both alkenes on hydrogenation give 2, 3-dimethylbutane. Predict the structure of X, Y and Z.
→
  1. What is the oxidation number of 'S'in H2SO5
  2. Balance the following equation:

$\text{Zn}\text{(s)}+\text{NO}_3^-\text{(aq)}\xrightarrow{ \ \ \ \ \ \ \ \ }\text{Zn}^{2+}\text{(aq)}+\text{NH}_4^+\text{(aq)}+\text{H}^+$ (Acidic medium)

→
Commercially available concentrated hydrochloric acid contains 38% HCl by mass.
  1. What is the molarity of the solution (density of solution = 1.19g mL- 1)?
  2. What volume of the above concentrated HCl is required to make 1.0L of 0.10M HCl?
→
The enthalpy of formation of methane at constant volume and temperature of 298 K is $- 7 3 . 4 0$ KJ , then find the enthalpy of formation of this reaction at constant pressure at same temperature.
→
Decide whether each of the following reaction involves oxidation reduction reaction or not. If it does, identify which species is oxidised and which gets reduced?
  1. $\ \ \ \ \ \ \ \ \ {\text{O}\ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \text{OH}}\\\ \ \ \ \ \ \ \ \ \ \|\ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ |\\ 4\text{CH}_3\text{CCH}_3+\text{LiAlH}_4+4\text{H}_2\text{O}\rightleftharpoons4\text{CH}_3\text{CHCH}_3+\text{LiOH}+\text{Al}(\text{OH})_3$
  2. $\text{CH}_3\text{CH}_2\text{OH}\xrightarrow{\ \text{H}_2\text{SO}_4\ \ }\text{CH}_2=\text{CH}_2+\text{H}_2\text{O}$
  3. $\ \ \ \ \ \ \ {\text{O}\ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \text{O}}\\\ \ \ \ \ \ \ \ \|\ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \ \|\\\text{CH}_3\text{C OH}+\text{CH}_3\text{NH}_2\rightleftharpoons\text{CH}_3\text{CO}^-+\text{CH}_3\text{NH}^+_3$
→
Predict the dipole moment of
i. a molecule of the type $AX _2$ having a linear geometry.
ii. a molecule of the type $AX _4$ having tetrahedral geometry.
iii. a molecule of the type $AX _2$ having angular geometry.
iv. a molecule of the type $AX _4$ having square planar geometry.
→

Identify the functional groups present in the following compounds.
