P-2 Similarity Maths - P-2 Similarity

Maharashtra Board - STD 10 - Maths (MSBSHSE - Semi English Medium). 211 questions in this chapter.

Question types

P-2 Similarity question types

211 questions across 6 question groups — pick any mix to generate a Maths paper with step-by-step answer keys.

211
Questions
6
Question groups
5
Question types
Sample Questions

P-2 Similarity questions

One sample from each question group in this chapter. Select any group above to see the full set with answer keys.

Q 1M.C.Q (1 Marks)1 Mark
Select the appropriate alternative.
In figure 1.71, seg XY || seg BC, then which of the following statements is true?

$A.\frac{A B}{A C}=\frac{A X}{A Y}$
$B.\frac{A X}{X B}=\frac{A Y}{A C}$
$C.\frac{A X}{Y C}=\frac{A Y}{X B}$
$D.\frac{A B}{Y C}=\frac{A C}{X B}$
View full solution →
Q 2M.C.Q (1 Marks)1 Mark
Select the appropriate alternative.
ΔABC and ΔDEF are equilateral triangles, A(ΔABC) : A(ΔDEF) = 1 : 2. If AB = 4 then what is length of DE?


  • A
    $2 \sqrt2$
  • B
    4
  • C
    8
  • ✓
    $4 \sqrt2$

Answer: D.

View full solution →
Q 3M.C.Q (1 Marks)1 Mark
Select the appropriate alternative.
In Δ and ΔDEF ∠B = ∠E, ∠F = ∠C and AB = 3DE then which of the statements regarding the two triangles is true?

A. The triangles are not congruent and not similar
B. The triangles are similar but not congruent.
C. The triangles are congruent and similar.
D. None of the statements above is true.
View full solution →
Q 4M.C.Q (1 Marks)1 Mark
Select the appropriate alternative.
If in ΔDEF and ΔPQR, ∠D ≅ ∠Q, ∠R ≅ ∠E then which of the following statements is false?

$A.\frac{E F}{P R}=\frac{D F}{P Q}$
$B.\frac{D E}{P Q}=\frac{E F}{R P}$
$C.\frac{D E}{Q R}=\frac{D F}{P Q}$
$D.\frac{E F}{R P}=\frac{D E}{Q R}$
View full solution →
Q 5M.C.Q (1 Marks)1 Mark
Select the appropriate alternative.
In Δ ABC and ΔPQR, in a one to one correspondence $\frac{A B}{Q R}=\frac{B C}{P R}=\frac{C A}{P Q}$ then

A. Δ PQR ~ Δ ABC
B. Δ PQR ~ Δ CAB
C. Δ CBA ~ Δ PQR
D. Δ BCA ~ Δ PQR
View full solution →
Q 6Complete the following activities and rewrite it : (2M)2 Marks
In figure 1.66, seg PQ || seg DE, A(Δ PQF) = 20 units, PF = 2 DP, then find A(DPQE) by completing the following activity.
A(Δ PQF) = 20 units, PF = 2 DP, Let us assume DP = x. ∴ PF = 2x
$DF = DP +\square=\square+\square=3 x$
In Δ FDE and Δ FPQ,
∠FDE ≅ ∠ .......... corresponding angles
∠FED ≅ ∠ ......... corresponding angles
∴ Δ FDE ~ Δ FPQ .......... AA test
$\therefore \frac{ A (\Delta FDE )}{ A (\Delta FPQ )}=\frac{\square}{\square}=\frac{(3 x )^2}{(2 x )^2}=\frac{9}{4}$
$A (\Delta FDE )=\frac{9}{4} A(\Delta FPQ )=\frac{9}{4} \times \square=\square$
$A (\square DPQE )= A (\Delta FDE )- A (\Delta FPQ )$
$\quad=\square-\square$
$\quad=\square$
View full solution →
Q 10Complete the following activities and rewrite it : (2M)2 Marks
In $\triangle A B C$, ray $B D$ bisects $\angle A B C . A-D-C$, side $D E \|$ side $B C, A-E-B$, then prove that $\frac{A B}{B C}=\frac{A E}{E B}$
In $\triangle A B C$, ray $B D$ bisects $\angle B$.
$\therefore \quad \frac{ AB }{ BC }=\frac{ AD }{ DC }$
In $\triangle ABC , DE \| BC$
$\therefore \quad \frac{ AE }{ EB }=\frac{ AD }{ DC }$
$\therefore \frac{ AB }{ ⬜ }=\frac{ ⬜ }{ EB }$
[Given]
[Angle biscetor theorem]
[Given]
⬜
[From (i) and (ii)]
View full solution →
Q 122 Marks Questions2 Marks
Prove The Theorem : The ratio of the intercepts made on a transversal by three parallel lines is equal to the ratio of the corrosponding intercepts made on any other transversal by the same parallel lines.
View full solution →
Q 142 Marks Questions2 Marks
Ratio of areas of two triangles with equal heights is 2 : 3. If base of the smaller triangle is 6 cm then what is the corresponding base of the bigger triangle?
View full solution →
Q 152 Marks Questions2 Marks
Areas of two similar triangles are 225 sq.cm & 81 sq.cm. If a side of the smaller triangle is 12 cm, then find corresponding side of the bigger triangle.
View full solution →
Q 163 Marks Question3 Marks
Prove The Theorem : If a line parallel to a side of a triangle intersects the remaining sides in two distinct points, then the line divides the sides in the same proportion.
View full solution →
Q 183 Marks Question3 Marks
In Δ ABC, B - D – C and BD = 7, BC = 20 then find following ratios.

$(1)\frac{ A (\Delta ABD )}{ A (\Delta ADC )}$
$(2)\frac{ A (\Delta ABD )}{ A (\Delta ABC )}$
$(3)\frac{ A (\Delta ADC )}{ A (\Delta ABC )}$
View full solution →
Q 224 Marks Questions4 Marks
Prove The Theorem : When two triangles are similar, the ratio of areas of those triangles is equal to the ratio of the squares of their corresponding sides.
View full solution →
Q 244 Marks Questions4 Marks
In fig 1.78, bisectors of ∠B and ∠C of ΔABC intersect each other in point X. Line AX intersects side BC in point Y. AB = 5, AC = 4, BC = 6 then find $\frac{AX}{XY}.$
View full solution →
Q 254 Marks Questions4 Marks
In the figure 1.76, seg PA, seg QB, seg RC and seg SD are perpendicular to line AD.
AB = 60, BC = 70, CD = 80, PS = 280 then find PQ, QR and RS.
View full solution →
Q 261 Marks Question1 Mark
If ΔABC ~ ΔPQR and AB: PQ = 2:3, then fill in the blanks.
$\frac{ A (\triangle ABC )}{ A (\Delta PQR )}=\frac{ AB ^2}{\square}=\frac{2^2}{3^2}=\frac{\square}{\square}$
View full solution →
Browse all question groups ↑

Generate a P-2 Similarity paper free

Pick question groups from the list above, set marks and difficulty, and export a branded PDF with step-by-step answer keys. First 3 chapters free — no signup.
