When a fork is seen through lenses A and B one by one, it appears as shown in the diagrams. What is the nature of (i) lens A, and (ii) lens B? Give reason for your answer.

Draw a ray diagram to show the formation of a virtual magnified image of an object by a convex lens. In your diagram, the position of object and image with respect to the principal focus should be shown clearly.

To find the image distance for varying object distances in case of a convex lens of focal length 15 cm, a student obtains on a screen a sharp image of a bright object by placing it at 20 cm distance from the lens. After that he gradually moves the object away from the lens and each time focuses the image on the screen.

1. In which direction-towards or away from the lens does he move the screen to focus the object?
2. How does the size of image change?
3. Approximately at what distance does he obtain the image of magnification -1?
4. How does the intensity of image change as the object moves farther and farther away from the lens?

What are the important differences between looking at a photograph of your face and looking at yourself in a plane mirror?

What type of lens is shown in the diagram on the right? What will happen to the parallel rays of light? Show by completing the ray diagram.

Light travels more quickly through water than through glass:

1. Which is optically denser: Water or glass?
2. If a ray of light passes from glass into water, which way will it bend: Towards the normal or away from the normal?

Define and show on a diagram, the following terms relating to a concave mirror:

1. Aperture.
2. Radius of curvature.

It is desired to obtain an erect image of an object, using concave mirror of focal length of 12cm.
Where will the image of this object be, if it is placed 24cm in front of the mirror? Draw ray diagram for this situation also to justify your answer.
Show the positions of pole, principal focus and the centre of curvature in the above ray diagrams.
