Derive the expression for the heat produced due to a current ‘I’ flowing for a time interval ‘t’ through a resistor ‘R’ having a potential difference ‘V’ across its ends. With which name is this relation known?
Download our app for free and get started
when an electric charge Q moves against a.p.d.V, the amount of work done is given by
$W = Q \times V .......(1)$
We know, current, $\text{I}=\frac{\text{I}}{\text{T}}$
$Q = I \times t .....(2)$
By ohm's law, $\frac{\text{V}}{\text{I}}=\text{R}$
$V = I \times R ........(3)$
Putting eqs. (2) and (3) in eq (1),
$W = I \times t \times I \times R$
$W = I^2RT$
Assuming that all the electrical work done is converted into heat energy, we get Heat produced, $H = I^2Rt$ joules
This relation is known as Joule's law of heating,
$W = Q \times V .......(1)$
We know, current, $\text{I}=\frac{\text{I}}{\text{T}}$
$Q = I \times t .....(2)$
By ohm's law, $\frac{\text{V}}{\text{I}}=\text{R}$
$V = I \times R ........(3)$
Putting eqs. (2) and (3) in eq (1),
$W = I \times t \times I \times R$
$W = I^2RT$
Assuming that all the electrical work done is converted into heat energy, we get Heat produced, $H = I^2Rt$ joules
This relation is known as Joule's law of heating,
